Engine
TypeLiquid Cooled V-8
Horsepower502
Torque567
BlockCast Iron - 4 bolt main
CylindersAluminum (110cc)
Valvetrain2.25“Int. / 1.88”Exh
Size502 c.i. (8200cc)
Compression9.6:1
CarburetorQuadrajet 850 cfm
Exhaust2.5“ with dual mufflers
Transmission2-speed semi-auto w/rev.
Final DriveBelt, Gates- Polychain

Dimensions
Wheel Base82.0”
Seat Height28.5“
Rake33.0 degrees
Grd. Dlearance4.5”
Frame Width31.0“
GVWR1827 lbs.
Dry Weight1300 lbs.

Tires/Wheels
Front130/90-16, 3.50”x16.0“
Rear230/60, 7.0”x15.0“

Suspension
Front60mm inverted forks, adj. preload 2.5” travel
RearDual 13.0“ coilover shocks, adj. preload

Brakes
FrontDual four-piston calipers, 12.6” floating disc
RearSingle four-piston caliper, 12.6" floating disk

Fuel
Tank8.5 gal.
Reserven/a
High/Low MPG18/13
